CPU
Quad-core ARM Cortex-A55, Neon and FP
主频
Frequency
1.9Ghz
图形处理单元
GPU
G52 2EE,
OpenGL ES1.1/2.0/3.0/3.1/3.2, Vulkan 1.1, OpenCL 2.0
神经网络处理单元
NPU
RK NN, 0.8Tops
内存
Memory
DDR4 capacity of 1GB/2GB/4G/8G
内置存储容量
Storage
8GB/16GB/32G eMMC5.1
显示屏接口
Built-in Display
LVDS/MIPI DSI, eDp,双lvds，Mipi接口 支持最大分辨率1080p,
板载背光
Backlight
onboard背光 up to 35V
触摸屏
Touch
提供I²C接口(可以支持电阻触摸，电容触摸)
网络
Network
具备RJ45接口，支持100M以太网
Has the RJ45 interface, support 100m Ethernet
具备wifi模块，支持Wi-Fi 802.11b/g/n协议
接口设备
Interface Device
USB 2.0 hub扩展3个USB host
支持双USB摄像头，支持双mipi csi摄像头
1个USB OTG
一路RS23、1路RS485,一路4线韦根，一个开门按钮，一个烟警/匪警输入接口，一个以太网接口
最大支持3W/4R单声道喇叭，模拟MIC输入/PDM数字mic阵列输入/带硬件回踩电路
音频
Audio
Up to 8 channels TX and 8 channels RX path
n Audio resolution from 16bits to 32bits
n Sample rate up to 192KHz
Up to 8 channels
n Audio resolution from 16bits to 24bits
n Sample rate up to 192KHz
n Support PDM master receive mode
supports up to 8 channels for TX and 8 channels RX path
n Audio resolution from 16bits to 32bits
n Sample rate up to 192KHz
视频图片
Video/Picture
Video Decoder
n H.265 HEVC/MVC Main10 Profile yuv420@L5.1 up to 4096x2304@60fps
H.264 AVC/MVC Main10 Profile yuv400/yuv420/yuv422/@L5.1 up to 4096x2304@60fps
n VP9 Profile0/2 yuv420@L5.1 up to 4096x2304@60fps
n VP8 verision2,up to 1920x1088@60fps
n VC1 Simple Profile@low, medium, high levels, Main Profile@low, medium, high levels, Advanced Profile@level0~3,up to 1920x1088@60fps
MPEG-4 Simple Profile@L0~6,Advanced Simple Profile@L0~5,up to 1920x1088@60fps
MPEG-2 Main Profile, low, medium and high levels, up to 1920x1088@60fps
MPEG-1 Main Profile, low, medium and high levels, up to 1920x1088@60fps
n H.263 Profile0,levels 10-70,up to 720x576@60fps
n Video output0, up to 4096x2304@60Hz resolution
n Video output1, up to 2048x1536@60Hz resolution
n Video output2, up to 1920x1080@60Hz resolution
l Video Encoder
n H.264/AVC BP/MP/HP@level4.2，up to 1920x1080@100fps
n H.265/HEVC MP@level4.1, up to 1920x1080@100fps (4096x4096@10fps with
TILE)
操作系统
System
Google Android 9.0
基本软件功能
Software Function
网页浏览、电子邮件、电子书、资源管理器
语言支持
Language
中文，英文等多国语言
行业分类 : 安防监控
开发平台 : Rockchip 瑞芯微
交付形式 : PCBA,整机,软件
性能参数 : 22纳米、内置ISP : 功耗更低；
应用场景 : 安防、智慧商显、工控定制
